CTXscan-1p is a unique one-way multi-energy portal designed for high throughput X-ray inspection of vehicles/trucks with cargo. It can detect smuggled goods, including plastic weapons and explosives, drugs, radioactive materials.
The main system components are the X-ray generators that produce high energy X-ray beams, and highly sensitive L-shaped detectors (each inspection channel has several detectors that allow to increase throughput).90%*
The CTXscan-1p combines powerful penetration and low radiation dosage. Due to the use of unique cyclic accelerator with ability of fast change of output energy, the system can penetrate the cabin with the truck’s driver using the lowest dosage, and after that switch to high dosage mode within microseconds. After the cabin passes through the portal, the system penetrates all truck with maximum dosage. Also the system can work in Cabin-cut mode, the system starts irradiation after the cabin with the truck’s driver. The scanning mode choice can be made due to the local radiation safety regulations that are used in the end-user country.
The system does not require any temperature-controlled permanent or solid built infrastructure and can operate 24/7. The system automatically inspects trucks moving at various speeds. Images are transmitted to the remote control room for further examination. CTXscan-1p is ideally suited for using at customs facilities, seaports and airports, border crossings. The system configuration allows fast and thorough inspection of 20/40/45ft sea containers and other freight up to 150 vehicles/trucks per hour in one way (channel) design.

CTXscanM (Mobile X-ray Vehicle Screening System) is designed for screen-ing bulky cargo and vehicles and detection of radioactive materials and explosives, as well as other restricted articles using radiometric and dosimetric surveillance equipment.
CTXscanM's 6/9MV X-ray imaging system is the most powerful and advanced X-ray inspection system available on the mobile vehicle screening systems market. Due to the usage of a cyclic accelerator with variable radiation energy, the system can operate in dual-energy mode that allows to discriminate organic and inorganic mater ial.
Mobility of CTXscanM improves detection of contraband goods as it can be deployed in non-typical and unexpected locations. System works in two scanning modes: system remains immobile, as the vehicles move through the portal (‘dynamic object’ mode) or the portal moves parallel to the inspected object (‘static object’ mode).
In the dynamic object mode it is possible to scan the cabin with the driver due to ability of changing high energy during inspection. As an additional option system can be enhanced with backscattered mode that allows to inspect vehicles and cargo from one side in case if there is no both side access. System with this additional option allows to detect radioactive and/or nuclear materials in active mode.

The CTXscan-MT is remotely operated self-propelled scanner designed to optimize security checks at ports, airports and border crossings. It reduces the need for manual inspection of complete trucks (cabin included), containers and vehicles by verifying manifests and checking for threats such as explosives, narcotics, weapons of mass destruction (WMDs) and contraband.
The CTXscan-MT uses betatron type accelerator with high energy level up to 9 MeV, allowing steel penetration 320 mm (standard) up to 340 mm (typical). A high maximum throughput of 25 trucks per hour can be achieved in scan mode; and a maximum of 150 trucks per hour in pass through mode.
High performance imaging equips operators with detailed radioscopic images of the container or vehicle to generate rapid and reliable results.
To military standards - 50 up to 70 degrees cyclic mode. Operators and image database are protected in case of anyincident on site.
Operators work outside safety zone. No danger to be radiated. No special permits and regular medical checks etc. Easy to handle. Possible to use multiple scanners close by each other on one site. Easy to extend a scanning capacity on the site of the same dimensions. The same crew can operate multiple scanners.
Based on a trailer chassis, the CTXscan-MT systems can be towed from site to site by a standard tracktor as required. Road clearance confirmed with all global road reulations. If offers ease of operations and a small footprint with minimal external infrastrutcure reqiuirements; and yet meets the most demanding, international security screening standards.
FEATURE HIGHLIGHTS

• Inspect bulky goods and vehicles in order to detect smuggling, illegal or prohibited goods, objects and explosives at ports,airports and border crossing
• Versatile operational modes:
• Pass-through (up to 150 trucks/hour)
• Mobile (up to 25 trucks/hour)
• Steel penetration – up to 340 mm 9MeV
• Lightweight – less than 6 tons/axle
• Fully automated chassis with remote operator cabin
• Advanced technology providing material discrimination and adjustable safety zone parameters

BETA-9132 is a unique multi-view multi-energy rail-mounted gantry designed for the inspection of sealed sea freight containers such as 20/40/45ft, consignments inside trucks and other vehicles. It can detect smuggled goods, including plastic weapons and explosives, drugs, radioactive materials.
The main system components are the X-ray generator, which produces high energy X-ray beam, and the highly sensitive L-shaped detector. BETA-9132 is designed in such a way that it is practically impossible to hide illegal items inside the inspected objects owing to the multiple imaging obtained from various perspectives. These perspectives are chosen in such a way that the hidden item will be surely seen from one of the multi-views regardless of its location inside the inspected object.

• The BETA-9132 combines powerful penetration and low radiation dosage. The system is normally located in a temperature controlled permanent or solid build infrastructure and can operate 24/7. The system automatically inspects vehicles without driver, placed between the rails (the gantry moves, images are transmitted to the remote control room over them) for further examination. BETA-9132 is ideally suited for applications at customs facilities, sea and airports, border crossings. Temperature controlled infrastructure
• Single or multy X-ray generator (betatron)
• L-shaped detector unit(s)
• Control unit
• Transportation unit

The system configuration allows fast and thorough inspection of 20/40/45ft sea containers and other freight up to 25-40 vehicles/trucks per hour.
